Helical Bevel Gear
Helical bevel gear refers to the tooth line on the crown wheel in the production shape. It is a straight bevel gear that does not pass through the cone top. Continuous bevel gear pair in the transmission process is relatively fewer teeth, easy to produce impact, information instability, and noise. Helical bevel gear pairs of bull gears and pinion gears have equal and opposite helical angles. Its fit degree is greater than that of straight bevel gear pair. Therefore, at high-speed operation, noise, and vibration are significantly reduced, and the number of helical teeth of the bevel gear pair can be relatively reduced so as to obtain a larger transmission ratio and compact structure.
Spiral Bevel Gear Parameter:
| Model Number | M3,M4,M5,M8,M12 and etc. |
| Material | Brass, C45 steel, Stainless steel, Copper, POM, Aluminum, Alloy, and so on |
| Surface treatment | Zinc-plated, Nickel plated, Passivation, Oxidation, Anodization, Geomet, Dacromet, Black Oxide, Phosphatizing, Powder Coating, and Electrophoresis |
| Standard | ISO, DIN, ANSI, JIS, BS, and Non-standard. |
| Precision | DIN6,DIN7,DIN8,DIN9. |
| Teeth treatment | Hardened, Milled, or Ground |
| Tolerance | 0.001mm-0.01mm-0.1mm |
| Finish | shot/sandblast, heat treatment, annealing, tempering, polishing, anodizing, zinc-plated |
| Items packing | Plastic bag+Cartons Or Wooden Packing |
| Payment terms | T/T, L/C |
| Production lead time | 20 business days for the sample,25 days for the bulk |
| Samples | Sample price range from $2 to $100. representative express request paid by clients |
| Application | 1. Automatic controlling machine 2. Semi-conductor industry 3. General industry machinery 4. Medical equipment 5. Solar energy equipment 6. Machine tool 7. Parking system 8. High-speed rail and aviation transportation equipment, etc. |
Helical Bevel Gear Feature:
Helical teeth: The teeth of helical bevel gears are angled, which makes for smooth and efficient power transmission. The crooked teeth also help reduce noise and vibration during operation.
Spiral pattern: The teeth are cut into a spiral pattern, which causes the teeth to come into contact with each other gradually. This helps reduce impact loads and gear wear.
High load capacity: Helical bevel gears can handle high loads and torque levels, making them ideal for heavy-duty applications such as mining, construction, and industrial machinery.
Versatility: Helical bevel gears can be designed to meet various specifications, including gear ratio, load capacity, and noise level. This makes them a common choice for many different applications.
Good efficiency: Instead of efficiency like spiral bevel gears, spiral bevel gears still offer good levels of efficiency, with some designs achieving up to 98% efficiency.
We are one of the best bevel gear suppliers. We can offer wide bevel gear stock. We have exported our products to clients worldwide and earned a good reputation because of our superior product quality and after-sales service. We welcome customers at home and abroad to contact us to negotiate business, exchange information, and cooperate with us!
Bevel Gear Uses:
Automotive applications: Bevel gears are commonly used in automotive differentials to transfer power from the drive shaft to the wheels. They are also used in steering systems and power take-off units.
Industrial machinery: Bevel gears are widely used in industrial machinery, such as machine tools, printing presses, packaging equipment, etc. They can be used to transmit power at right angles between axes, or to change the direction of rotation.
Robotics and automation: Bevel gears are widely used in robotics and automation systems, where they can be used to transmit power, change the direction of motion, and adjust the speed of rotational motion.
Household appliances: Bevel gears are used in many household appliances such as washing machines, vacuum cleaners and power tools. They are used to transfer power between the motor and the drive shaft, or to change the direction of motion.
Marine applications: Bevel gears are used in Marine propulsion systems, where they transfer power from the engine to the drive shaft. They are also used in steering systems and winches.
